| Introduction |
DebugView is an
application that lets you monitor debug output on your local system, or any
computer on the network that you can reach via TCP/IP. It is capable of
displaying both kernel-mode and Win32 debug output, so you dont need a
debugger to catch the debug output your applications or device drivers
generate, nor do you need to modify your applications or drivers to use
non-standard debug output APIs. DebugView works on Windows 95, Windows 98, Windows Me,
Windows NT 4, Windows 2000 and Whistler Beta 1.
|
| DebugView Capture |
Under Windows
95, Windows 98, and Windows Me DebugView will capture output from the
following sources:
- Win32
OutputDebugString
- Win16
OutputDebugString
- Kernel-mode
Out_Debug_String
- Kernel-mode
_Debug_Printf_Service
Under Windows NT, Windows 2000,
and Whistler Beta 1 DebugView will capture:
- Win32
OutputDebugString
- Kernel-mode
DbgPrint
- All kernel-mode variants of
DbgPrint implemented in Whistler (the successor to Windows 2000) Beta 1
|
| DebugView Capabilites |
DebugView has a powerful array of
features for controlling and managing debug output.
Here are features new to
version 4.0:
- Terminal services aware: When you run
DebugView in a remote terminal services session you can capture debug
output from that session as well as from the console session.
- Administrators membership optional:
The account from which you run DebugView requires no special privileges
for capturing Win32 output. If you want to capture kernel-mode output the
account requires the "load driver" privilege, which members of the
administrators group hold.
- Multiple hilighting filters: Create up
to five differenent highlighting filters to highlight debug output that matches
your filters, and even customize the highlighting colors used for each
filter.
- Minimize to tray: You can minimize
DebugView to the system tray so that it captures output without taking
up screen real-estate.
- Command-line options: DebugView
supports command-line options that allow you to launch it in the system tray
and to automatically start logging output to a file.
- Millisecond timestamps:
DebugView's clock-time mode now supports millisecond resolution.
Here is a list highlighting some of
DebugView's other features:
- Remote monitoring: Capture kernel-mode
and/or Win32 debug output from any computer accessible via TCP/IP - even across
the Internet. You can monitor multiple remote computers simultaneously.
DebugView will even install its client software itself if you are
running it on a Windows NT/2K system and are capturing from another Windows
NT/2K system in the same Network Neighborhood.
- Most-recent-filter lists:
DebugView remembers your most recent filter selections, with an
interface that makes it easy to reselect them.
- Process ID option: Toggle the display
of process IDs for Win32 debug output.
- Clipboard copy: Select multiple lines
in the output window and copy their contents to the clipboard.
- Log-to-file: Write debug output to a
file as its being captured.
- Printing: Print all or part of captured
debug output to a printer.
- One-file payload: DebugView is
implemented as one file.
- Crash-Dump Support: DebugView
can recover its buffers from a crash dump and save the output to a log file so
that users can send you the output your NT driver generated right up to the
time of a crash.
The on-line help-file describes all these
features, and more, in detail.
|
| Installation and Use |
Simply execute the
DebugView program file (dbgview.exe) and DebugView will
immediately start capturing debug output. To run DebugView on Windows 95
you must get the
WinSock2
update from Microsoft. Note that if you run DebugView on Windows
NT/2K dbgview.exe must be located on a non-network drive and you must have
administrative privilege. Menus, hot-keys, or toolbar buttons can be used to
clear the window, save the monitored data to a file, search output, change the
window font, and more. The on-line help describes all of DebugView's
features.
|
| Sample Screenshot |
This is a screenshot
of DebugView capturing Win32 debug output from a remote system. Note the
presence of a highlighting filter. |
In order to help us
track its use, please download through the link that represents the operating
system on
which you will use or mostly use DebugView.
Note that the zip files are identical, and
DebugView runs on either
platform.
Download
DebugView (x86 - 161KB) - you plan on using DebugView on
Win9x/Me
Download
DebugView (x86 160KB) - you plan on using DebugView on
WinNT/2K
Download DebugView (Alpha - 170KB)
|
